JACKODUR® Plus 300 Gefiniert GL

The XPS insulation board with excellent insulation performance and maximum adhesion.

Textured surface provides excellent adhesion.

Made of extruded polystyrene foam (XPS), JACKODUR® Plus is ideally suited for a wide range of construction applications that require excellent insulation performance and compressive strength. The textured (“gefiniert”) surface with its waffle pattern also ensures optimum adhesion.

Product characteristics JACKODUR® Plus 300 Gefiniert GL:

High compressive strength 300 kPa
Outstanding lambda value with low installation height: λ_D = 0.027 W/(m·K)
Textured (“gefiniert”) surface with square edges
Insulation thicknesses from 50 mm to 200 mm
Good dimensional stability, moisture resistance, and rot resistance

Benefits JACKODUR® Plus 300 Gefiniert GL:

25 % greater insulation efficiency at comparable insulation thicknesses
Excellent adhesive characteristics thanks to textured surface
Secure single-layer installation up to 200 mm
Time and cost-saving installation

Ideal application JACKODUR® Plus 300 Gefiniert GL:

Cast in concrete formwork
Under slab insulation
Insulation under screed
Insulated render or plaster board
Refrigerated warehouse under slab insulation
Thermal bridge insulation

Image 1 / 4
Image 2 / 4
Image 3 / 4
Image 4 / 4

Downloads to the product

Data sheets

JACKODUR Plus 300 Gefiniert (pdf; 642 KB)

Technical data

JACKODUR Technical Specifications (pdf; 156 KB)

Brochures

JACKODUR Produktkatalog und Preisliste

JACKODUR Catalogue (pdf; 5 MB)

Approvals & Test Certificates

Breeam Fact Sheet JACKODUR Plus (pdf; 283 KB)

EPD JACKODUR Plus (pdf; 2 MB)

Leed Fact Sheet JACKODUR Plus (pdf; 271 KB)

Safety data sheets

JACKODUR Plus (pdf; 211 KB)

Ideal applications for JACKODUR® Plus 300 Gefiniert GL

Plinth insulation under plaster Optimal thermal and moisture protection in the perimeter area.

Thermal bridge insulation Save heating costs sustainably with JACKODUR®.

Insulation under screed The right choice for industrial screed insulation.
